Chipset

Atheros QCA9563 + QCA9882 +QCA8035

Standard

802.11ac/b/g/n, MIMO technology

Memory

128MB DDR2 RAM

Flash

16MB

Interface

1 * 10/100 /1000Mbps RJ45 WAN Port

1 * Reset button, press 15 seconds to revert to default setting

Antenna

Build in 18dBi Panel Antenna

Power consumption

48V PoE<30W

Size

L: 410mm, W: 20.5mm, H: 105 mm

  Weight

3KGS

Frequency

2.4G : 802.11b/g/n ; 5GHz：802.11a/n/ac

2.4GHz、5GHz

Country code

FCC、IC、ETSI、MKK、MKK1、MKK2、MKK3、NCC、RUSSIAN、CN

Modulation

OFDM = BPSK,QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Throughput

1200 Mbps

Operation mode

Wireless AP, Gateway, WISP, WiFi Repeater

WAN Type

Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access)

Wireless Security

64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption

SSID

Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G)

Firewall

DoS, SPI Firewall,

IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding

Protocols

IPv4

Package Contents

1200Mbps Dual Band wireless access point

Ethernet Cable

Quick Installation

Guide Setting Accessory

System Requirements

Microsoft Windows 98 SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux

Environment

Operating Temperature: 0~40 ℃(32 ℉~104℉) Storage Temperature: -40~70 ℃ (-40 ℉~158℉)
Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing

Management

Firmware GUI , Remote Management, WLAN Controller, Cloud Management System
