槍型網路攝影機

型號 : AAL-B2-001VF

槍型網路攝影機200萬畫素適用於下列用途.

1. 廠房監視系統

2.連鎖商店監視系統

3.道路監控系統

4.數位廣播系統

5.河川監視系統

6.高速移動監視系統

7.太陽能網路監視系統

槍型網路攝影200萬畫素機軟體功能:

1.電子圍籬

2.人臉辨識

3.智能追蹤 Auto tracking

4.Fail over

5.斷線影像自動回補

6.4k 魚眼

7.H.265

8.回放智慧搜尋



Camera

Sensor

1/2.8", 2 Megapixel, progressive scan CMOS

Shutter

Auto/Manual, 1/6~1/8000s

Lens

2.8~12mm @F1.4; Angle of view: 90° ~ 28°

Zoom/Focus

Manual

Min. Illumination

Colour: 0.06 Lux (F1.4, 50IRE)

Black & White: 0.03Lux (F1.4, 50IRE)

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>52dB

Video

Max. Resolution

1920 × 1080

Video Compression

H.264,MJPEG

Frame Rate

1080P (1920*1080) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps

9:16 Corridor Mode

Supported

ROI

Supported

Video Streaming

Triple

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

Audio

Audio Compression

G.711

Two-way audio

Supported

Storage

Edge Storage

Micro SD, up to 64 GB

Network

Protocols

L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP,

HTTP,SNMP,SIP

Compatible Integration

ONVIF, IMOS,API

Interface

Audio I/O

Audio cable

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

1 / 1

Network

10M/100M Base-TX Ethernet

General

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: 3.5W (5.5W with IR on)

Material

Cast aluminum

Dimensions (L × W × H)

253.4 ×86 ×71.7 mm (9.98” × 3.4” × 2.8”)

Weight

0.93 kg (2.05 lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Ingress Protection

IP66

Optics

•Day/night functionality

•Smart IR technology

•3D DNR (Digital Noise Reduction)

Compression

•Triple streams

•ROI (Region of Interest)

•9:16 corridor mode

•Customized OSD

Network

•ONVIF Conformance

Structure

 • Support PoE power supply

 •Wide temperature range: -35°C to 60°C (-31°F to 140°F)

 •Wide voltage range of ±25%

 • IP66
