2.4GHz MIMO 無線網路基地台
2.4G MIMO 150Mbps Wireless Solution
型號 :
AAP-OM2425
|
Standards Compliance
|
IEEE 802.11 n；IEEE 802.11b/g；IEEE 802.3；IEEE 802.3u
|
|
Chipsets Solution
|
Atheros AR9331
|
|
Radio Frequency Type
|
DSSS/OFDM
|
|
Modulation
|
DSSS with CCK，DQPSK，DBPSK OFDM with BPSK，QPSK，16QAM，64QAM
|
|
SDRAM
|
32 M Byte
|
|
Flash
|
8 M Byte
|
|
Frequency Band
|
America/FCC：2.412~2.462 GHz Europe CE/ETSI：2.412~2.472 GHz
|
|
Sensitivity
|
IEEE 802.11b：-92dBm @ 1Mbps；-87dBm @ 11Mbps，PER < 8%
IEEE 802.11g：-88dBm @ 6Mbps；-73dBm @ 54Mbps，PER < 10%
IEEE 802.11n：-88dBm @ MCS0；-70dBm @ MCS7，HT20.
-85dBm @ MCS0；-67dBm @MCS7，HT40
|
|
Antenna Type
|
Omni Antenna
|
|
Access Point Interfaces
|
Auto sensing MDI/MDI-X Ethernet 10/100 Base-TX：RJ-45 x 2
|
|
Operation Mode
|
AP、WDS、Client Bridge + Universal Repeater
|
|
Operating Environment
|
Operating Temperature：-30 ~ +70°C；Operating Humidity：10~90%
|
|
Power
|
POE 12~24 Volt + 5 % / 1A (Max.) AC adapter AC 100V ~ 240V
|
|
Material
|
Plastic
|
|
Warranty
|
One year limited
|
